Turn your forklift or skidsteer into a tow rig — In Seconds
TorqFork is a rotating tow-ball attachment that sits within the fork’s thickness, so you can switch from lifting to towing and back—without removing anything.
Patented Utility Invention — US 12,208,652
Fits Standard Equipment
Class 2 - Forks Only
Dual Ball Sizes: 2" & 2-5/16"
Tows When You Need It
Rotate vertical to expose the hitch ball and move trailers, generators, job boxes, and more.
Disappears When You Don’t
Keep it horizontal and your forks operate normally—no removal, no slowdown.
Two Ball Sizes, One Tool
2" and 2-5/16" balls on board for the most common hitches.
Always On-Tool Storage
All parts store and lock directly on the fork—hard to lose, easy to find.
How It Works
Step 1: Lift Mode
TorqFork sits flush within the fork’s thickness, so operators run standard lifts without interference.
Technical specs
| Component | Details |
|---|---|
| Fork Compatibility | Forks made from 2" thick hardened steel. |
| Ball Sizes | 2" and 2-5/16" (2.3125"). |
| Mechanism | Rotating ball assembly with pull handle; sits within fork thickness. |
| Pins | Quick-release pin + four-prong tempered-steel locking pin. |
| Main Materials | Tempered steel assembly; hardened steel fork interface. |
| Patent | US 12,208,652 (Utility). |
Get TorqFork for Your Shop
One kit. Two ball sizes. Instant towing on the forklift you already own.
Rotating ball assembly
2" ball & 2-5/16" ball
Quick-release & locking pins
Install guide
Step 2: Rotate to Tow
Pull the handle, rotate the assembly vertically, and the hitch ball is exposed for towing. Secure with the locking pin.
Step 3: Lock + Go
Quick-release pin and tempered-steel locking pin keep the ball in position while you maneuver the load.
Step 4: Back to Lift
Rotate back to horizontal to return to normal fork operations—no tool changeover.
Built for oem’s, dealers & fleets
Volume pricing & scheduled deliveries
Engineering support & fit guidance
Dealer training assets
FAQ’s
Is TorqFork compatible with my forklift?
Yes, class II Designed around 2" thick tempered forks and standard attachments. Check your dimensions or request our drawing.
Which hitch balls are included?
2" and 2-5/16"—the most common industrial sizes.
Do I have to remove it for regular lifts?
No. In the horizontal position, your forks operate normally.
How long does install take?
Minutes. Assembly stores and locks on the fork so it’s always ready.
Is it patented?
Yes—Utility Patent US 12,208,652.
SAFETY & USE
Tow only within your forklift and hitch/ball rated capacities.
Use on level surfaces with secured loads and trained operators.
Verify pin engagement and ball size before moving any load.
Follow facility protocols and applicable standards.
